Takeuchi Tb138fr Parts Operators Manual
This collection contains the following two manuals:
Takeuchi TB138FR parts book.
Serial No.13810003-
353 pages
File type PDF
This is a fully illustrated parts list with exploded views. It can be a valuable tool to assist disassembly and assembly
Takeuchi TB138FR operators manual.
Serial number
TB138FR: 13810003up
TB153FR: 15820004up
TB180FR: 17830004up
ENGINE
EPA Interim Tier 4 Compliant
Automatic Fuel Bleed System
Extended Life Coolant
Dual Element Air Cleaner
ELECTRICAL
Electronic Monitoring System that Includes Visual and
Audible Alarms for Low Oil Pressure, High Engine Coolant
Temperature, Air Cleaner Restriction, and Charge Level
12 volt System with 40 amp Alternator
Work Lights: Canopy – ROPS and Boom
Cab – Front Pillar and Boom
Engine Preheat
Hour Meter
Travel Alarm
UNDERCARRIAGE AND FRAME
Triple Flange Track Rollers
Sloped Frame with Open Centers
2-Speed Travel with Automatic Shift
Heavy Duty Dozer Blade
Cast Iron Wrap Around Protective Counterweight
13.8” Rubber or Steel Tracks
HYDRAULIC
Cushioned Boom and Arm Cylinders
Pilot Controls
Primary Auxiliary Hydraulic Circuit Plumbed to Arm with
1-Way and 2-Way Operation
Accumulator
Hydraulic Oil Cooler with Sight Gauge
