JD X728 Service Repair Manual
Attachment overview: TM2349
48″ mid-mount mower deck
54″ mid-mount mower deck
62″ mid-mount mower deck
60″ mid-mount mower deck
Front-stop loader
Garden tractors can use tillers, plows, or different ground-attractive attachments. Cat Excavator is now no longer listing information of those attachments.
48″ Mower deck:
JD 48X
48 inches
121 cm
3-blade
hydraulic lift
Cut height: 1 to 5.25 inch
2 to 13 cm
Cut adjustments: 18
117 lbs
53 kg.
54″ Mower deck:
JD 54X
54 inches
137 cm
Total width: 64.5 inches
163 cm
3-blade
hydraulic lift
Cut height: 1 to 5.25 inch
2 to 13 cm
Cut adjustments: 18
170 lbs
77 kg.
62″ Mower deck:
JD 62X
62 inches
157 cm
3-blade
hydraulic lift
Cut height: 1 to 5.25 inch
2 to 13 cm
Cut adjustments: 18
200 lbs
90 kg
60″ Mower deck
JD 7-Iron
60 inches
152 cm
Total width: 61.3 inches
155 cm
3-blade
hydraulic lift
Cut height: 1 to 5.25 inch
2 to 13 cm
Cut adjustments: 18
342 lbs
155 kg.
JD 45 Loader:
Loader weight 515 lbs
233 kg
Height (to pin) 73 inches
185 cm
Clearance, dumped bucket 57 inches
144 cm
Dump reach 23 inches
58 cm
Dump angle 45°
Reach at ground 43.25 inches
109 cm
Rollback at ground 25°
Breakout force (lift) 770 lbs
349 kg
Breakout force (bucket) 740 lbs
335 kg
Lift to full height (at pin) 365 lbs
165 kg
Bucket capacity 0.2 cu yd
0.2 cu m
Bucket width 48 inches
121 cm
