JD 544K 4WD Loader Technical Manual TM13144X19
(SN. D000001 – D001000)
- Manual Included:
- Repair Technical Manual: 388 Pages (TM13144X19)
- Specifications:
- Brand: JD
- Model: 544K 4WD
- Serial Number: (PIN: 1BZ544K_ D000001 – D001000)
- Type: Loader
- Manuals: Repair Technical manual and Operation and Test Manual
- Publication Numbers: TM13144X19
- Language: English
- Format: PDF
Operation and Test Manual: 1156 Pages (TM13142X19)
JD 544K 4WD Loader Technical Manual TM13144X19
| Section | Section Description | Group | Components & Systems |
|---|---|---|---|
| 00 | General Information | 0001 / 0003 | Safety & Torque Values |
| 01 | Wheels | 0110 | Powered Wheels and Fasteners |
| 02 | Axles and Suspension Systems | 0200 / 0225 | Removal, Installation, Drive Shafts & U-Joints |
| 0250 / 0260 | Axle Shaft, Bearings & Hydraulic System | ||
| 03 | Transmission | 0300 / 0350 | Removal, Gears, Shafts & Power Shift Clutches |
| 0360 | Transmission Hydraulic System | ||
| 04 | Engine | 0400 | Engine Removal and Installation |
| 05 | Engine Auxiliary System | 0505 / 0510 | Cold Weather Starting & Cooling Systems |
| 0520 / 0530 | Intake & External Exhaust Systems | ||
| 0560 | External Fuel Supply Systems | ||
| 07 | Damper Drive | 0752 | Damper Elements |
| 09 | Steering System | 0960 | Steering Hydraulic System |
| 10 | Service Brakes | 1011 / 1060 | Active Elements & Hydraulic System |
| 11 | Park Brake | 1111 / 1160 | Active Elements & Hydraulic System |
| 17 | Frame or Supporting Structure | 1740 / 1746 | Frame Installation & Bottom Guards |
| 1749 | Chassis Weights | ||
| 18 | Operator’s Station | 1800 / 1810 | Removal, Installation & Operator Enclosure |
| 1821 / 1830 | Seat, Seat Belt, Heating & Air Conditioning | ||
| 19 | Sheet Metal and Styling | 1910 | Hood or Engine Enclosure |
| 31 | Loader | 3102 / 3140 | Bucket and Loader Frames |
| 3160 | Loader Hydraulic System | ||
| 99 | Dealer Fabricated Tools | 9900 | Dealer Fabricated Tools |
