ZAXIS 60USB-3 n Engine Rated Power: 54 hp (40.5 kW) @ 2,000 rpm n Operating Weight: 13,653 lb (ca. 6 t). (6193 kg)
n Backhoe Bucket: 6.8 cu. ft. (0.19 m3)
Engine
● Certified to EPA interim Tier-4 emissions ● Engine coolant to –34 deg. F (–37 deg. C) ● Engine preheater
● Fan guard
● Fuel/water separator
● Full-flow oil filter
● Isolation mounted
● Key start switch with electric fuel shutoff ● Single dry-type air filter
● Under-hood muffler
Hydraulic System
● Auxiliary function foot control
● Auxiliary hydraulic lines with quick-couplers
to the end of the boom.
Hitachi Zaxis 60USB-3 Hydraulic Excavator Factory Workshop Manuals
● Auxiliary return-flow selector valve
● Axial-piston swing motor
● Boom-swing foot control
● Excavator-to-backhoe control pattern
change valve
● Closed-center load sensing with one
variable-displacement pump and one
fixed-gear pump
Operator’s Station
● Horn
● Hour meter
● Instrumentation lights
● Monitor system: Preheat indicator / Engine
oil pressure indicator / Alternator voltage indicator / Fuel gauge and fuel level indicator / Engine coolant temperature gauge and engine coolant temperature indicator / Hour meter / Work lights indicator
● Motion alarm with cancel switch
● Propel levers and foldable pedals
● Two travel speeds with automatic shifting ● Seat belt, 2 in. (51 mm), retractable
● Suspension seat (cloth)
▲ Front screen
▲ Rear secondary exit kit
