Fiat-Hitachi Fb90.2 Fb100.2 Fb110.2 Service Repair Manual
Wheel Loader .
This manual contains deep information about maintaining, assembly, disassembly and servicing.
TABLE OF CONTENTS:
SECTION 00 HEALTH, SAFETY, MAINTENANCE
1 General
2 General Specifications
3 Tooling
SECTION 10 ENGINE NEW HOLLAND 92 to 108 hp
1 Engine
2 Fuel System
3 Turbocharger
4 Lubrication System
5 Cooling System
SECTION 17 TORQUE CONVERTER
1 With Powershuttle Transmission
2 With Powershift Transmission
SECTION 21 TRANSMISSIONS
1 4×4 Compact Shuttle
2 Powershift Introduction
3 Powershift Operating Lever
4 Powershift Overhaul (includes 4 Wheel Steer)
SECTION 25 FRONT AXLES
1 Front Axle (2 and 4 Wheel Drive Only)
2 Front Axle (4 Wheel Steer Only)
SECTION 27 REAR AXLES
1 Rear Axle with Foot Operated Diff Lock (2 and 4 Wheel Drive Only)
2 Rear Axle with Electrically Operated Diff Lock (2 and 4 Wheel Drive Only)
3 Rear Axle (4 Wheel Steer Only)
SECTION 33 BRAKE SYSTEMS
1 Brakes (2 and 4 Wheel Drive Only)
2 Brakes (4 Wheel Steer Only)
SECTION 35 HYDRAULIC SYSTEMS
1 Hydraulic Circuits and Components (REXROTH ONLY)
2 Fault Finding, Pressure and Flow Testing
3 Hydraulic Cylinders
SECTION 39 VEHICLE CHASSIS
1 CHASSIS COMPONENTS
SECTION 41 STEERING SYSTEMS
1 Steering (2 and 4 Wheel Drive Only)
2 Steering (4 Wheel Steer Only)
SECTION 50 CAB HEATING AND AIR CONDITIONING
1 Cab Heating
2 Air Conditioning
SECTION 55 ELECTRICAL SYSTEM
1 System General
2 Wiring Diagrams
3 Starter Motor
4 Alternator
5 Battery
6 Service Diagnostics, Calibration and Immobiliser
7 Component Testing
SECTION 82 LOADER REMOVAL
1 OVERHAUL (2 and 4 Wheel Drive Only)
2 OVERHAUL (4 Wheel Steer Only)
SECTION 84 BACKHOE REMOVAL
1 OVERHAUL
SECTION 90 CAB PARTS
