CASE 9010b Hydraulic Excavator Operators Pdf Manual Download
Case 9010 Excavator Service Repair Manual
Manual Covers:
To The Owner Of a Case Machinery
Identification Numbers/ Machine Components
Safety/Decals/Hand Signals
Instruments And Controls
Operating Instructions
Tracks
Lubrication/Maintenance Charts,
Lubrication/ Fiters /Fluids,
Maintenance And Lubrication,
Electrical System
Specifications
Machine Storage
Index
After Delivery Check
And More.
Case 9010 Excavator Operators Pdf Manual Download
Specification
Engine
Make Case
Model 4TA-390
Net Power 106 hp 79 kw
Power Measured @ 2200 rpm
Displacement 239 cu in 3.9 L
Torque Measured @ 1600 rpm
Max Torque 290 lb ft 393.2 Nm
Number of Cylinders 4
Aspiration Turbocharged and Aftercooled
Operational
Operating Weight 28000 lb 12700.6 kg
Fuel Capacity 63.4 gal 240 L
Cooling System Fluid Capacity 4.1 gal 15.7 L
Hydrauilc System Fluid Capacity 32.8 gal 124 L
Engine Oil Capacity 2.7 gal 10.4 L
Swing Drive Fluid Capacity 0.58 gal 2.2 L
Operating Voltage 24 V
Alternator Supplied Amperage 45 amps
Hydraulic System Relief Valve Pressure 4550 psi 217.9 kPa
Hydraulic Pump Flow Capacity 32 gal/min 121 L/min
Swing Mechanism
Swing Speed 13.4 rpm
Undercarriage
Number of Shoes per Side 44
Shoe Size 23.6 in 599.4 mm
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader & WinZip
